Safi Works Form R32.1 Road Frameset - Oyster Grey
S
$4,265.00 AUD
Skip to product information
(We can only consider Australian retailers)
| Variant | SKU | Barcode |
|---|---|---|
| S | 00321 | — |
| M | 00322 | — |
| L | 00323 | — |
| XL | 00324 | — |
<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>
Pre-order
ETA: Jan 2027
Precision-engineered in Copenhagen and built for riders who want a modern steel platform without compromise. The R32.1 pairs a Columbus Spirit and Life tubed front triangle with a Safi-developed rear triangle, delivering the ride quality steel is loved for alongside genuinely progressive geometry — a steeper seat tube, longer reach and higher stack for a more capable, race-ready position.
Every frameset-specific component — fork, head tube, dropouts and seatpost clamp — is designed in-house, yet remains fully compatible with aftermarket parts. The result is a frame that's easy to build up exactly how you want it, without locking you into proprietary solutions
Details
- Columbus Spirit and Life steel tubing (front triangle) with a Sabi-developed rear triangle
- Engineered in Copenhagen, Denmark; manufactured in Taichung, Taiwan
- Available as a frameset with an in-house designed carbon fork
- Optional Polymer Workshop components available
- Headset, top cone and bottom bracket available as add-ons
- ED-coated for long-term corrosion protection
- Fits tyres up to 32 mm with 4 mm clearance
- Frame and fork tested beyond ISO standards
- Fully internal cable routing, T47/68 bottom bracket
- Compatible with electronic groupsets only
- Stock sizes, ready to ship
Geometry
| Measurement | S | M | L | XL | |
|---|---|---|---|---|---|
| a | Seat tube length | 515 | 535 | 555 | 585 |
| b | Top tube length | 504 | 529 | 546.2 | 565.4 |
| c | Stack | 540 | 555 | 575.1 | 605.1 |
| d | Reach | 385 | 395 | 403 | 410 |
| e | Seat tube angle | 76.7° | 75.5° | 75° | 74.5° |
| f | Head tube angle | 73.1° | 73.4° | 73.6° | 73.9° |
| g | Head tube length | 125.9 | 142.7 | 163 | 196.3 |
| h | Wheelbase | 968.1 | 981.2 | 993 | 1009.2 |
| i | Fork rake / length | 43 / 370 | 43 / 370 | 43 / 370 | 43 / 370 |
| j | Trail | 60 | 58 | 57 | 55 |
| k | Chainstay length | 405 | 405 | 405 | 407 |
| l | Front center | 575.9 | 588.2 | 600.2 | 612.5 |
| m | Bottom bracket drop | 77 | 75 | 72 | 72 |
Mfr Claimed Weight
Frame: 1.9 kg | Fork: 410 g
