ZEB is built for the most extreme terrain—steep double-black runs, freeride features, and even the pedal back up if that’s in the cards. The all-new LinearXL air spring delivers a coil-like ride—supple off the top, supportive through the mid-stroke, and backed by Adjustable Bottom Out (ABO) for confident end-stroke control—giving you unwavering consistency and predictability. Found only in our Ultimate forks, ButterWagonTech ensures a constant supply of oil to the bushings, reducing friction, and maintaining smooth performance throughout the entire service interval. Intuitive HSC/LSC controls on the Charger 3.2 damper with ButterCups technology make setup fast, understandable, and easy to communicate. ZEB delivers the composure riders need to confidently pick their line and hold it—no matter how extreme the trail.

Features
NEW LinearXL air spring delivers a consistent and predictable ride feel backed by adjustable bottom out (ABO) for end-stroke control
NEW ButterWagonTech ensures a constant supply of oil to the bushings, reducing friction and maintaining smooth performance throughout the entire service interval
NEW Charger 3.2 damper with new rebound/compression tunes that match LinearXL air spring achieves virtually silent performance, keeping riders focused on the trail
NEW control bezel with numbered compression adjuster for intuitive adjustments—start at "0" and easily add or decrease damping
NEW integrated short fender mount (ZEB Integrated Fender included)
NEW graphics package—minimalist design, maximum impact
ButterCups technology block 20% of high-frequency “trail chatter” to reduce hand and arm fatigue
Low-grab SKF wiper seals deliver long-lasting fork performance and a smoother ride
Maxima 920 blended 15w reduces overall fork friction
Available in Electric Red or Ultimate High Gloss Black Signature colorways

Specifications
Wheel size: 27.5", 29"
Travel (mm): 150mm, 160mm, 170mm, 180mm
Damper Type: Charger 3.2 RC2 W/ButterCups
Fork offset: 38mm (27.5"), 44mm (27.5"), 44mm (29")
Color (FS): Electric Red - Gloss, Gloss Black
E-Bike Approved: E-bike Approved, E-bike Approved w/E-MTB Decal
Steerer: 1.5" Tapered, 1.8" Tapered
Axle: 15x110mm BOOST™ TC Compt
Upper tube type: 38mm aluminum
Damper adjust: Crown
Volume reducer: 0/3 Tokens, 0/4 Tokens, 1/4 Tokens, 1/5 Tokens
Spring: Linear XL W/ButterCup
Max Tire Width (mm): 74.5
Maximum Rotor Size: 220mm
Minimum Rotor Size: 200mm
Fender Compatibility: Bolt On - Short (Use AC-FEN-EDRO-A1)
Bottom Out: Externally Adjustable Bottom Out
Compression tune: C5
Rebound tune: R55

Mfr Claimed Weight
TBC
