The perfect grip for any adventure. Our newly developed Newmen gravel bike handlebars offer a level of ergonomics and performance that is second to none. We worked closely with a biomechanic to develop the ergonomic shape, cross-sections and bends. With a downsweep and frontsweep of 4° each, a moderate flare of 12.5° and a reach of 75mm, it provides a natural hand position for maximum comfort on long gravel adventures and multi-day trips. Down- and frontsweep allow for a natural hand position even when your arms are narrower than shoulder width. The short reach leaves plenty of room for the forearms in the lower links. The cut-out on the drop (110mm) relieves pressure on the thumb joint and the drop-shaped design of the drop ensures a secure and comfortable grip in rough passages. In addition, we have kept the handlebars thinner in the drop so that you can fit a thicker, more comfortable handlebar tape without the handlebars becoming too thick.

The Advanced G Gravel dropbar is available in a range of widths (400-460mm) to suit your needs. The lightweight carbon gravel dropbar starts at 200 grams (400mm). Flexible cable routing also makes the carbon gravel handlebars extremely versatile: both internal routing through the stem (electronic shifting, two brake cables) and external routing in channels are possible with the Advanced G Gravel handlebars.

Attention!! Due to the oval shape of the drops it is not possible to mount the Shimano junction box EW RS910 for 11-speed Di2 into the barends.

Specifications
Size: 400/445mm
Reach: 75mm
Drop: 110mm
Flare: 12.5°
Max. System Weight: 130kg
Intended Use: Gravel
Aerobar Compatible: No
Di2 Compatible: No
2-Bolt Stem Compatible: No
Material: Carbon
Bar Width: 400mm / 420mm / 440mm / 460mm

Mfr Claimed Weight
200g
