Updated May-2020
- Crankset weights will vary depending on size and length.
- Cassettes are 11-28 (or closest)
- We've removed bottom bracket weight as these are frame dependant.
- Note: SRAM eTap component weights includes batteries because batteries all weigh the same.
- Note: SRAM HRD shifter weights include the cables, brake hose and caliper.
- Note: Di2 weights do not include wiring/junction box/battery. The reason why is because there is a host of different wire length + junction options and weight will fluctuate with setup.
- Note: Mechanical weights do not include cabling.
- Note: Disc brake weights do not include brake hose/fluid.
- GRX Groupset total weight does not include cassette and chain. Choose from any appropriate 11spd/10spd option.
Mechanical Shift (Rim) | Shifters | Rear D. | Front D. | Cranks | Cass. | Chain | Brakes | Total |
---|---|---|---|---|---|---|---|---|
Dura-Ace R9100 | 365 | 158 | 70 | 614 | 193 | 247 | 326 | 1973 |
Ultegra R8000 | 438 | 200 | 92 | 674 | 251 | 257 | 360 | 2272 |
105 R7000 | 500 | 225 | 95 | 713 | 284 | 257 | 379 | 2453 |
Dura-Ace 9000 | 363 | 160 | 60 | 636 | 192 | 249 | 294 | 1960 |
Ultegra 6800 | 419 | 193 | 86 | 694 | 251 | 260 | 340 | 2243 |
105 5800 | 486 | 234 | 89 | 736 | 284 | 260 | 378 | 2467 |
Red 22 | 280 | 145 | 69 | 609 | 167 | 246 | 262 | 1778 |
Force 22 | 307 | 178 | 79 | 697 | 257 | 256 | 280 | 2054 |
Super Record 12 | 339 | 181 | 79 | 618 | 266 | 220 | 311 | 2014 |
Record 12 | 343 | 216 | 81 | 708 | 266 | 220 | 326 | 2160 |
Chorus 12 | 364 | 215 | 82 | 727 | 337 | 247 | 318 | 2290 |
Super Record 11 | 342 | 166 | 71 | 603 | 177 | 239 | 297 | 1895 |
Record 11 | 348 | 170 | 75 | 651 | 201 | 239 | 309 | 1993 |
Chorus 11 | 350 | 183 | 76 | 683 | 230 | 250 | 302 | 2074 |
Electronic Shift (Rim) | Shifters | Rear D. | Front D. | Cranks | Cass. | Chain | Brakes | Total |
Dura-Ace Di2 R9150 | 230 | 197 | 104 | 614 | 193 | 247 | 326 | 1911 |
Ultegra Di2 R8050 | 295 | 240 | 132 | 674 | 251 | 257 | 360 | 2209 |
Dura-Ace Di2 9070 | 237 | 217 | 114 | 636 | 192 | 249 | 294 | 1939 |
Ultegra Di2 6870 | 315 | 271 | 167 | 694 | 251 | 260 | 340 | 2298 |
Red eTap AXS | 283 | 299 | 167 | 561 | 211 | 255 | 267 | 2043 |
Force eTap AXS | 303 | 326 | 176 | 744 | 266 | 269 | 303 | 2387 |
Red eTap | 260 | 239 | 187 | 609 | 167 | 246 | 262 | 1970 |
Super Record EPS 12 | 280 | 234 | 132 | 618 | 266 | 220 | 230 | 1980 |
Super Record EPS 11 | 262 | 198 | 127 | 603 | 188 | 238 | 311 | 1927 |
Record EPS 11 | 266 | 203 | 133 | 651 | 211 | 238 | 326 | 2028 |
Mechanical Shift (Disc) | Shifters | Rear D. | Front D. | Cranks | Cass. | Chain | Brakes | Total |
Dura-Ace R9120 | 538 | 158 | 70 | 614 | 193 | 247 | 256 | 2076 |
Ultegra R8020 | 554 | 200 | 92 | 674 | 251 | 257 | 286 | 2314 |
105 R7020 | 610 | 225 | 95 | 713 | 284 | 257 | 294 | 2478 |
Red 22 HRD | 748 | 145 | 69 | 609 | 167 | 246 | - | 1984 |
Force 22 HRD | 765 | 178 | 79 | 697 | 257 | 256 | - | 2232 |
Super Record Disc 12 | 462 | 181 | 79 | 618 | 266 | 220 | 230 | 2056 |
Record Disc 12 | 463 | 216 | 81 | 708 | 266 | 220 | 230 | 2184 |
Chorus Disc 12 | 503 | 215 | 82 | 727 | 337 | 247 | 255 | 2366 |
Rival 1 HRD | 749 | 270 | - | 806 | 423 | 270 | - | 2518 |
Force 1 HRD | 770 | 270 | - | 596 | 366 | 256 | 2258 | |
GRX RX810 1X | 572 | 274 | - | 655 | - | - | 280 | TBC |
GRX RX810 2X | 572 | 274 | 94 | 722 | - | - | 280 | TBC |
GRX RX600 1X | 611 | 274 | - | 753 | - | - | 280 | TBC |
GRX RX600 2X | 611 | 274 | 94 | 819 | - | - | 280 | TBC |
GRX RX400 10Spd | 613 | 303 | 96 | 819 | - | - | 280 | TBC |
Electronic Shift (Disc) | Shifters | Rear D. | Front D. | Cranks | Cass. | Chain | Brakes | Total |
Dura-Ace Di2 R9170 | 320 | 197 | 104 | 614 | 193 | 247 | 256 | 1931 |
Ultegra Di2 R8070 | 360 | 240 | 132 | 674 | 251 | 257 | 286 | 2200 |
Red eTap AXS HRD | 467 | 299 | 167 | 561 | 211 | 255 | 282 | 2242 |
Force eTap AXS HRD | 476 | 326 | 176 | 744 | 266 | 269 | 346 | 2603 |
Red eTap HRD | 788 | 239 | 187 | 609 | 167 | 246 | - | 2236 |
Super Record EPS Disc 12 | 381 | 234 | 132 | 618 | 266 | 220 | 236 | 2087 |
GRX RX815 1X | 565 | 288 | - | 655 | - | - | 280 | TBC |
GRX RX815 2X | 565 | 288 | 131 | 722 | - | - | 280 | TBC |
