Reba has always signified RockShox quality and performance. Even more so now, with new chassis options that allow Reba to be a frontrunner in any role, from XC to trail riding. With technologies developed on SID, Reba and Revelation, Reba is the one-stop solution to everyone looking for the unmistakable RockShox performance in a proven package.
Features
Motion Control RL damper with adjustable low speed compression and lockout with blow-off valve
Solo Air lets you add air to your forks through a single Schrader valve
filling both the positive and negative air spring chambers simultaneously
Fast Black coating on the upper tubes provides improved durability and decreased friction
Sag Gradients are printed right on the fork's upper tubes
making perfect suspension setup easy and accurate
Air Guides - starting pressures noted on the back of the fork help you set up your suspension in seconds instead of minutes
| Specifications |
| Axle to Crown Length |
506 |
| Brake Type |
Post Mount 160 |
| Color |
Black |
| Crown Race |
40 |
| Defined Color |
Black |
| Designed for ebike |
Yes |
| External Adjustments |
Low Speed Compression Damping |
| External Adjustments |
Rebound Damping |
| Front Axle |
15mm Thru x 100mm |
| Lockout Switch |
Crown |
| Maximum Tire Width |
62 |
| Negative Spring |
Air |
| Offset |
51 |
| Positive Spring |
Air |
| S.H.I.S. Stem Clamp Diameter |
28.6 |
| Stanchion Diameter |
32 |
| Steerer Tube Length (mm) |
245 |
| Steerer Type |
Tapered |
| Travel (mm) |
100 |
| Wheel Size |
29" |
